Enclosed Speakers
Plug‑and‑Play Audio Solutions
Speakers Optimized for Performance and Design
Same Sky's enclosed speakers are designed for superior sound quality and simplified design integration. The models are available in rectangular, round, square, or oval frame shapes with compact packages as small as 20 x 13 mm and profiles as low as 4.87 mm. Featuring wire lead terminations, multiple cone types, Neodymium magnets, and sound pressure levels (SPLs) from 86 to 109 dB at 0.1 m, these enclosed speakers are ideal for a range of consumer, industrial, medical, and security applications. Several enclosed speaker models also offer IPX7 or IP67 ratings for dealing with moisture and environmental contaminants.
Highlights
- Enclosed speaker design
- SPLs from 86 to 109 dB
- Wire lead terminations
- Profiles as low as 4.87 mm
- IPX7 or IP67 rated models available
CES-20134-088PM
20 x 13 mm, Enclosed, Rectangular Case, 0.8 W, 8 Ohm, Neodymium Magnet, PEEK Cone, Wire Leads, Speaker |
CES-20134-088PMA
20 x 13 mm, Enclosed, Rectangular Case, 0.8 W, 8 Ohm, Neodymium Magnet, PEEK Cone, Wire Leads with Connector, Speaker |
CES-20134-088PMB
20 x 13 mm, Enclosed, Rectangular Case, 0.8 W, 8 Ohm, Neodymium Magnet, PEEK Cone, Wire Leads with Connector, Speaker |
CES-24156-18PM-67
24 x 6.55 mm, Enclosed, Oval Case, 1 W, 8 Ohm, Neodymium Magnet, PEEK Cone, Wire Leads, Speaker |
CES-24208-18PM-X7
24 x 6.55 mm, Enclosed, Oval Case, 1 W, 8 Ohm, Neodymium Magnet, PEEK Cone, Wire Leads, IPX7, Speaker |
CES-2704-088L050
27 x 4.9 mm, Enclosed, Round Case, 0.8 W, 8 Ohm, Neodymium Magnet, PEEK Cone, Wire Leads, Speaker |
CES-2704-088L050A
27 x 4.9 mm, Enclosed, Round Case, 0.8 W, 8 Ohm, Neodymium Magnet, PEEK Cone, Wire Leads with Connector, Speaker |
CES-2704-088L050B
27 x 4.9 mm, Enclosed, Round Case, 0.8 W, 8 Ohm, Neodymium Magnet, PEEK Cone, Wire Leads with Connector, Speaker |
CES-3210-18PM-67
32.4 x 10.35 mm, Enclosed, Round Case, 1.5 W, 8 Ohm, Neodymium Magnet, PEI Cone, Wire Leads, Speaker |
CES-32166-18PM-X7
32 x 6.5 mm, Enclosed, Rectangular Case, 1 W, 8 Ohm, Neodymium Magnet, PEEK Cone, Wire Leads, IPX7, Speaker |
CES-403015-24PM-67
40 x 15 mm, Enclosed, Rectangular Case, 2 W, 4 Ohm, Neodymium Magnet, PEI Cone, Wire Leads, Speaker |
CES-50508-24PM-67
50 x 8.7 mm, Enclosed, SquareCase, 2 W, 4 Ohm, Neodymium Magnet, PEI Cone, Wire Leads, Speaker |
CES-571423-28PM
57.5 x 23 mm, Enclosed, Rectangular Case, 2 W, 8 Ohm, Neodymium Magnet, Cloth Cone, Wire Leads, Speaker |
CES-571423-28PMA
57.5 x 23 mm, Enclosed, Rectangular Case, 2 W, 8 Ohm, Neodymium Magnet, Cloth Cone, Wire Leads with Connector, Speaker |
CES-571423-28PMB
57.5 x 23 mm, Enclosed, Rectangular Case, 2 W, 8 Ohm, Neodymium Magnet, Cloth Cone, Wire Leads with Connector, Speaker |
CES-6123-34PM-67
61.09 x 23.35 mm, Enclosed, Round Case, 3 W, 4 Ohm, Neodymium Magnet, PET Cone, Wire Leads, Speaker |
CES-231210-18PM
24 x 13 mm, Enclosed, Rectangular Case, 1 W, 8 Ohm, Neodymium Magnet, PEEK Cone, Wire Leads with Connector, Speaker |
CES-361811-18PM-67
25 x 15.6 mm, Enclosed, Rectangular Case, 1 W, 8 Ohm, Neodymium Magnet, PEEK Cone, IP67, Speaker |
CES-26138-16L030
26 x 13 mm, Enclosed, Rectangular Case, 1.2 W, 6 Ohm, Neodymium Magnet, PEEK Cone, Wire Leads with Connector, Speaker |
CES-271911-158PM
27.1 x 19.2 mm, Enclosed, Rectangular Case, 1.5 W, 8 Ohm, Neodymium Magnet, Foam Cone, Wire Leads with Connector, Speaker |
CES-30207-158L120-67
30 x 20 mm, Enclosed, Rectangular Case, 1.5 W, 8 Ohm, Neodymium Magnet, PEN Cone, IP67, Speaker |
CES-302611-158PM-67
30 x 25.6 mm, Enclosed, Rectangular Case, 1.5 W, 8 Ohm, Neodymium Magnet, PU and PEI Cone, Wire Leads with Connector, IP67, Speaker |
CES-303206-240L40-67
30 x 20 mm, Enclosed, Rectangular Case, 2 W, 4 Ohm, Neodymium Magnet, PEN Cone, Wire Leads with Connector, IP67, Speaker |
CES-361810-18PM
35.9 x 18.5 mm, Enclosed, Rectangular Case, 1 W, 8 Ohm, Neodymium Magnet, PEEK Cone, Wire Leads with Connector, Speaker |
CES-391715-18PM-67
39 x 17.5 mm, Enclosed, Rectangular Case, 1 W, 8 Ohm, Neodymium Magnet, PU and PEI Cone, Wire Leads with Connector, IP67, Speaker |
CES-39209-28PM
39 x 20 mm, Enclosed, Rectangular Case, 2 W, 8 Ohm, Neodymium Magnet, Cloth Cone, Wire Leads with Connector, Speaker |
CES-3990-158PM-67
39 mm, Enclosed, Round Case, 1.5 W, 8 Ohm, Neodymium Magnet, PET Cone, Wire Leads with Connector, IP67, Speaker |
CES-403015-24130L
40 x 30 mm, Enclosed, Rectangular Case, 2 W, 4 Ohm, Neodymium Magnet, Paper and Cloth Cone, Wire Leads with Connector, Speaker |
CES-434313-28PM-67
43.5 x 43.5 mm, Enclosed, Square Case, 2 W, 8 Ohm, Neodymium Magnet, PEN Cone, Wire Leads with Connector, IP67, Speaker |
CES-503528-28PM-67
50 x 35 mm, Enclosed, Rectangular Case, 2 W, 8 Ohm, Neodymium Magnet, PEI Cone, Wire Leads with Connector, IP67, Speaker |
CES-603318-24PM
60 x 33 mm, Enclosed, Rectangular Case, 2 W, 4 Ohm, Neodymium Magnet, Cloth Cone, Speaker |
CES-703116-28PM
70 x 31 mm, Enclosed, Rectangular Case, 2 W, 8 Ohm, Neodymium Magnet, Paper and Cloth Cone, Speaker |
CES-703316-28PM
70 x 33 mm, Enclosed, Rectangular Case, 2 W, 8 Ohm, Neodymium Magnet, Paper and Cloth Cone, Speaker |
CES-803118-28PM
80 x 31 mm, Enclosed, Rectangular Case, 2 W, 8 Ohm, Neodymium Magnet, Cloth Cone, Speaker |
CES-885955-26PM
87.5 x 58.9 mm, Enclosed, Rectangular Case, 2 W, 6 Ohm, Neodymium Magnet, PEEK Cone, Speaker |
