Signal Relays

Same Sky’s signal relays are ideal for low-level current switching with max switching currents of 2 A or 3 A. Our low signal relays feature SPDT (1 Form C) or DPDT (2 Form C) contact forms, contact ratings of 120/125 Vac or 24 Vdc at 1 A, and AuAg overlay contact material. With max switching voltages of 120/125/220 Vac or 30/60 Vdc, our signal relays carry coil power ratings from 150 to 450 mW and coil voltages from 3 to 24 Vdc.

Filters | Reset All
Coil Voltage (V)
dropdn-arrow
3
5
9
12
24
Reset
Nominal Coil Power (mW)
dropdn-arrow
150
200
330
450
Reset
Contact Form
dropdn-arrow
DPDT (2 Form C)
SPDT (1 Form C)
Reset
Contact Rating
dropdn-arrow
120
125
Reset
Contact Rating VDC @ 1 A
dropdn-arrow
24
30
Reset
Max Switching Voltage (VAC)
dropdn-arrow
120
125
220
Reset
Max Switching Voltage (VDC)
dropdn-arrow
24
30
60
Reset
Max Switching Current (A)
dropdn-arrow
2
3
Reset
Length (mm)
dropdn-arrow
10.2
12.3
15.6
20.3
Reset
Width (mm)
dropdn-arrow
7.3
7.4
9.9
10.6
Reset
Height (mm)
dropdn-arrow
10
10.2
11.4
11.8
Reset
Series
dropdn-arrow
SR1
SR10
SR11
SR2
SR3
SR5
SR7
Reset

Results 35
Show
Model Number Coil Voltage (V) Nominal Coil Power (mW) Contact Form Contact Rating Contact Rating VDC @ 1 A Max Switching Voltage (VAC) Max Switching Voltage (VDC) Max Switching Current (A) Series Operating Temp Range (°C) Dimensions LxWxH (mm) Contact Material
24 200 DPDT (2 Form C) 120 24 125 30 2 SR11 -25 ~ 70 20.3 x 9.9 x 11.4 AuAg Overlay
12 200 DPDT (2 Form C) 120 24 125 30 2 SR11 -25 ~ 70 20.3 x 9.9 x 11.4 AuAg Overlay
9 200 DPDT (2 Form C) 120 24 125 30 2 SR11 -25 ~ 70 20.3 x 9.9 x 11.4 AuAg Overlay
5 200 DPDT (2 Form C) 120 24 125 30 2 SR11 -25 ~ 70 20.3 x 9.9 x 11.4 AuAg Overlay
3 200 DPDT (2 Form C) 120 24 125 30 2 SR11 -25 ~ 70 20.3 x 9.9 x 11.4 AuAg Overlay
24 450 DPDT (2 Form C) 120 24 125 30 2 SR10 -25 ~ 70 20.3 x 9.9 x 11.4 AuAg Overlay
12 450 DPDT (2 Form C) 120 24 125 30 2 SR10 -25 ~ 70 20.3 x 9.9 x 11.4 AuAg Overlay
9 450 DPDT (2 Form C) 120 24 125 30 2 SR10 -25 ~ 70 20.3 x 9.9 x 11.4 AuAg Overlay
5 450 DPDT (2 Form C) 120 24 125 30 2 SR10 -25 ~ 70 20.3 x 9.9 x 11.4 AuAg Overlay
3 450 DPDT (2 Form C) 120 24 125 30 2 SR10 -25 ~ 70 20.3 x 9.9 x 11.4 AuAg Overlay
24 200 SPDT (1 Form C) 120 24 220 30 3 SR7 -25 ~ 70 15.6 x 10.6 x 11.8 AuAg Overlay
12 200 SPDT (1 Form C) 120 24 220 30 3 SR7 -25 ~ 70 15.6 x 10.6 x 11.8 AuAg Overlay
9 200 SPDT (1 Form C) 120 24 220 30 3 SR7 -25 ~ 70 15.6 x 10.6 x 11.8 AuAg Overlay
5 200 SPDT (1 Form C) 120 24 220 30 3 SR7 -25 ~ 70 15.6 x 10.6 x 11.8 AuAg Overlay
3 200 SPDT (1 Form C) 120 24 220 30 3 SR7 -25 ~ 70 15.6 x 10.6 x 11.8 AuAg Overlay
24 200 SPDT (1 Form C) 120 24 220 30 3 SR5 -25 ~ 70 15.6 x 10.6 x 11.8 AuAg Overlay
12 200 SPDT (1 Form C) 120 24 220 30 3 SR5 -25 ~ 70 15.6 x 10.6 x 11.8 AuAg Overlay
9 200 SPDT (1 Form C) 120 24 220 30 3 SR5 -25 ~ 70 15.6 x 10.6 x 11.8 AuAg Overlay
5 200 SPDT (1 Form C) 120 24 220 30 3 SR5 -25 ~ 70 15.6 x 10.6 x 11.8 AuAg Overlay
3 200 SPDT (1 Form C) 120 24 220 30 3 SR5 -25 ~ 70 15.6 x 10.6 x 11.8 AuAg Overlay
24 150 SPDT (1 Form C) 125 24 125 60 2 SR3 -40 ~ 70 12.3 x 7.3 x 10.2 AuAg Overlay
12 150 SPDT (1 Form C) 125 24 125 60 2 SR3 -40 ~ 70 12.3 x 7.3 x 10.2 AuAg Overlay
9 150 SPDT (1 Form C) 125 24 125 60 2 SR3 -40 ~ 70 12.3 x 7.3 x 10.2 AuAg Overlay
5 150 SPDT (1 Form C) 125 24 125 60 2 SR3 -40 ~ 70 12.3 x 7.3 x 10.2 AuAg Overlay
3 150 SPDT (1 Form C) 125 24 125 60 2 SR3 -40 ~ 70 12.3 x 7.3 x 10.2 AuAg Overlay
