Ultrasonic Transceivers

Same Sky's ultrasonic transceivers combine the transmit and receive functions into a single package, providing you with a simplified solution for distance measurement, object detection, and proximity sensing. Our ultrasonic transceivers feature distance ratings up to 18 meters, beam angles from 7 up to 80 degrees, and frequency ratings from 25 to 400 kHz. Several models also carry IP67 or IP68 ratings for dealing with harsh environments.

Filters | Reset All

Range (m)

0.03 ~ 0.8

0.05 ~ 1

0.1 ~ 2

0.2 ~ 15

0.2 ~ 18

0.25 ~ 5

0.3 ~ 6

0.3 ~ 6.5

0.4 ~ 6.5

0.5 ~ 2

0.5 ~ 15

Reset

Frequency (kHz)

Min

Max

200

300

400

Reset

Rated Voltage (Vp-p)

Min

Max

100

150

400

500

Reset

Directivity (°)

Min

Max

Reset

Operating Temp MIN (°C)

≤ -40

≤ -20

Reset

Operating Temp MAX (°C)

≥ 60

≥ 70

≥ 80

Reset

Case Type

Aluminum

Plastic

Reset

Length (mm)

Min

Max

9.8

9.9

16.5

17.4

Reset

Width (mm)

Min

Max

9.8

9.9

16.5

17.4

Reset

Height (mm)

Min

Max

7.3

Reset

IP Rating

IP67

No IP Rating

IP68

Reset

Product Release New Products

Purchase Buy Online at sameskydevices.com Normally Stocked in Distribution

Resources 3D Model Available PCB Footprint Available

Results 28

of 2

	Dimensions LxWxH (mm)	Mounting Style	Range (m)	Frequency (kHz)	Rated Voltage (Vp-p)	Directivity (°)	Case Type
CUSA-TR11-010-1150-WC67 NEW!	9.9 x 9.9 x 7	Wire Leads with Connector	0.05 ~ 1	300	100	11	Aluminum
CUSP-TR12-010-1150-TH NEW!	9.9 x 9.9 x 7.3	Through Hole	0.05 ~ 1	300	50	9	Plastic
CUSA-TR11-010-1150-TH67 NEW!	9.9 x 9.9 x 7	Through Hole	0.05 ~ 1	300	100	11	Aluminum
CUSA-TR11-010-1150-W67 NEW!	9.9 x 9.9 x 7	Wire Leads	0.05 ~ 1	300	100	11	Aluminum
CUSP-TR12-010-1150-W NEW!	9.9 x 9.9 x 7.3	Wire Leads	0.05 ~ 1	300	50	9	Plastic
CUSP-TR12-010-1150-WC NEW!	9.9 x 9.9 x 7.3	Wire Leads with Connector	0.05 ~ 1	300	50	9	Plastic
CUSA-TR801-065-2000-TH68	18 x 18 x 12	Through Hole	0.3 ~ 6.5	40	150	80	Aluminum
CUSA-TR80-065-2000-TH68	16 x 16 x 10	Through Hole	0.3 ~ 6.5	40	150	80	Aluminum
CUSA-TR071-01-400-TH67	13 x 13 x 9	Through Hole	0.05 ~ 1	300	400	7	Aluminum
CUSA-TR65-065-2200-WC68	14 x 14 x 9	Wire Leads with Connector	0.4 ~ 6.5	40	150	65	Aluminum
CUSA-TR65-065-2200-W68	14 x 14 x 9	Wire Leads	0.4 ~ 6.5	40	150	65	Aluminum
CUSA-TR65-065-2200-TH68	14 x 14 x 9	Through Hole	0.4 ~ 6.5	40	150	65	Aluminum
CUSA-TR60-06-2200-WC68	14 x 14 x 9	Wire Leads with Connector	0.3 ~ 6	48	150	60	Aluminum
CUSA-TR60-06-2200-W68	14 x 14 x 9	Wire Leads	0.3 ~ 6	48	150	60	Aluminum
CUSA-TR60-06-2000-WC68	17.4 x 17.4 x 9	Wire Leads with Connector	0.3 ~ 6	48	150	60	Aluminum
CUSA-TR60-06-2000-W68	17.4 x 17.4 x 9	Wire Leads	0.3 ~ 6	48	150	60	Aluminum
CUSA-TR60-02-2000-TH67	10 x 10 x 7	Through Hole	0.5 ~ 2	40	150	60	Aluminum
CUSA-TR50-150-2500-WC68	25 x 25 x 12	Wire Leads with Connector	0.5 ~ 15	25	150	50	Aluminum
CUSA-TR50-150-2500-W68	25 x 25 x 12	Wire Leads	0.5 ~ 15	25	150	50	Aluminum
CUSA-TR50-05-2000-WC68	14 x 14 x 9	Wire Leads with Connector	0.25 ~ 5	58	150	60	Aluminum
CUSA-TR50-05-2000-W68	14 x 14 x 9	Wire Leads with Connector	0.25 ~ 5	58	150	60	Aluminum
CUSA-TR09-02-1000-TH67	19 x 19 x 11	Through Hole	0.1 ~ 2	200	500	9	Aluminum
CUSA-TR07-008-500-TH67	11 x 11 x 11	Through Hole	0.03 ~ 0.8	400	400	7	Aluminum
CUSA-TR07-01-400-TH67	10 x 10 x 7	Through Hole	0.05 ~ 1	300	400	7	Aluminum
CUSP-TR80-18-2400-TH	16.5 x 16.5 x 21	Through Hole	0.2 ~ 18	39	150	80	Plastic
