Stepper Servo Motors

Same Sky's stepper servo motors pair compact NEMA 8, 11, 14, 17, and 23 stepper motors with our AMT incremental encodersAMT incremental encoders for a reliable motor and motion control feedback solution. Our stepper servo motors offer holding torques up to 270 oz-in (1.90 N-m) and resolutions up to 4096 PPR. The encoders are fully programmable and in combination with the motor, provide closed-loop feedback when paired with a controller for a complete servo system.

Filters | Reset All
Frame Size
dropdn-arrow
NEMA 08
NEMA 11
NEMA 14
NEMA 17
NEMA 23
Reset
Max Holding Torque (oz-in)
dropdn-arrow
Min
Max
GO
3
4
7.5
9.2
12
13.7
16.6
42
63
83
85
110
170
270
Reset
Current/Phase (A)
dropdn-arrow
Min
Max
GO
0.35
0.45
0.6
0.67
0.7
0.8
1.05
1.3
1.33
1.4
2
2.1
2.8
4.2
Reset
Resistance/Phase (Ω±10%)
dropdn-arrow
Min
Max
GO
0.3
0.5
0.7
1.1
1.2
1.3
1.8
1.9
2
2.5
2.7
2.8
3.8
4.5
5.2
5.4
5.6
6.5
7.1
8.5
8.6
9.9
10.8
Reset
Inductance/Phase (mH±20%)
dropdn-arrow
Min
Max
GO
0.39
0.63
1.15
1.2
1.46
1.5
1.7
2.18
2.32
2.34
2.91
3.08
3.09
3.82
4.1
4.79
4.8
5.46
5.77
6.16
9.36
12.52
12.76
21.84
Reset
Max Optimal Speed (RPS)
dropdn-arrow
Min
Max
GO
1
2
3
5
6
7
9
11
13
16
20
22
24
30
44
Reset
Shaft Ø (mm)
dropdn-arrow
4
5
6.35
Reset
Length (in)
dropdn-arrow
Min
Max
GO
1.02
1.26
1.3
1.34
1.58
1.7
1.74
1.77
1.89
2.01
2.22
2.34
3.1
Reset
Series
dropdn-arrow
NEMA08-AMT112S
NEMA11-AMT112S
NEMA14-AMT112S
NEMA17-AMT112S
NEMA23-AMT112S
Reset

Results 24
Show
Model Number Frame Size Max Holding Torque (oz-in) Current/Phase (A) Resistance/Phase (Ω±10%) Inductance/Phase (mH±20%) Max Optimal Speed (RPS) Shaft Ø (mm) Length (in) Operating Temp Range (°C) Series Rated Voltage (Vdc)
NEMA 23 270 2.8 1.1 3.82 5 6.35 3.1 -20 ~ 50 NEMA23-AMT112S 24 ~ 80
NEMA 23 270 1.4 4.5 12.76 2 6.35 3.1 -20 ~ 50 NEMA23-AMT112S 24 ~ 80
NEMA 23 170 4.2 0.5 1.2 9 6.35 2.22 -20 ~ 50 NEMA23-AMT112S 24 ~ 80
NEMA 23 170 2.1 1.8 4.8 3 6.35 2.22 -20 ~ 50 NEMA23-AMT112S 24 ~ 80
NEMA 23 85 2.8 0.7 1.15 11 6.35 1.74 -20 ~ 50 NEMA23-AMT112S 24 ~ 80
NEMA 23 85 1.4 2.8 4.1 6 6.35 1.74 -20 ~ 50 NEMA23-AMT112S 24 ~ 80
NEMA 23 85 4.2 0.3 0.39 24 6.35 1.74 -20 ~ 50 NEMA23-AMT112S 24 ~ 80
NEMA 23 85 2.1 1.2 2.18 13 6.35 1.74 -20 ~ 50 NEMA23-AMT112S 24 ~ 80
NEMA 17 42 0.67 9.9 12.52 6 5 1.34 -20 ~ 50 NEMA17-AMT112S 24 ~ 48
NEMA 17 42 1.33 2.5 3.09 11 5 1.34 -20 ~ 50 NEMA17-AMT112S 24 ~ 48
NEMA 17 63 0.7 10.8 21.84 3 5 1.58 -20 ~ 50 NEMA17-AMT112S 24 ~ 48
NEMA 17 63 1.4 2.7 5.46 6 5 1.58 -20 ~ 50 NEMA17-AMT112S 24 ~ 48
NEMA 17 83 1.05 1.3 9.36 5 5 1.89 -20 ~ 50 NEMA17-AMT112S 24 ~ 48
NEMA 17 83 2.1 5.2 2.34 9 5 1.89 -20 ~ 50 NEMA17-AMT112S 24 ~ 48
NEMA 17 110 2 2 2.91 7 5 2.34 -20 ~ 50 NEMA17-AMT112S 24 ~ 48
NEMA 14 7.5 0.35 8.5 5.77 20 5 1.02 -20 ~ 50 NEMA14-AMT112S 24 ~ 48
NEMA 14 7.5 0.45 3.8 2.32 30 5 1.02 -20 ~ 50 NEMA14-AMT112S 24 ~ 48
NEMA 11 16.6 1.3 1.9 1.46 22 5 2.01 -20 ~ 50 NEMA11-AMT112S 24 ~ 48
NEMA 11 16.6 0.67 8.6 6.16 11 5 2.01 -20 ~ 50 NEMA11-AMT112S 24 ~ 48
NEMA 11 12 1.3 1.3 0.63 44 5 1.77 -20 ~ 50 NEMA11-AMT112S 24 ~ 48
NEMA 11 13.7 0.67 7.1 4.79 13 5 1.77 -20 ~ 50 NEMA11-AMT112S 24 ~ 48
NEMA 11 9.2 0.67 5.6 3.08 16 5 1.26 -20 ~ 50 NEMA11-AMT112S 24 ~ 48
NEMA 08 4 0.8 5.4 1.5 1 4 1.7 -20 ~ 50 NEMA08-AMT112S 24 ~ 48
NEMA 08 3 0.6 6.5 1.7 1 4 1.3 -20 ~ 50 NEMA08-AMT112S 24 ~ 48
Results 24
Show
