Multi-Stage Peltier Modules

With two modules stacked for improved heat pumping capabilities, Same Sky's multi-stage Peltier modules are able to achieve higher temperature deltas up to 105°C, while retaining the solid-state benefits of single-stage thermoelectric coolers. Our multi-stage Peltier modules feature current ratings from 2.8 to 10 A and range in size from 26.25 to 41.25 mm.

Filters | Reset All
Imax (A)
dropdn-arrow
Min
Max
GO
2.8
3.6
3.9
5
6
6.8
8.5
10
Reset
Vmax (V)
dropdn-arrow
Min
Max
GO
12.8
14.2
15.7
16
16.1
16.7
25.6
Reset
Qmax (Th=27°C) (W)
dropdn-arrow
Min
Max
GO
8.7
18
21
23
32
40
51.6
62
99
Reset
Qmax (Th=50°C) (W)
dropdn-arrow
Min
Max
GO
9.6
19.8
23
25
35
45
58
68
109
Reset
ΔTmax (Th=27°C)
dropdn-arrow
82
83
85
95
Reset
ΔTmax (Th=50°C)
dropdn-arrow
92
93
95
105
Reset
Width (mm)
dropdn-arrow
30
40
45
50
Reset
Height (mm)
dropdn-arrow
Min
Max
GO
6.35
6.65
6.7
6.8
7.05
7.2
7.4
7.5
Reset
Length (mm)
dropdn-arrow
Min
Max
GO
26.25
30
31.25
40
40.5
41.25
Reset
Series
dropdn-arrow
CP100
CP28-2
CP39H-2
CP50-2
CP60H-2
CP68H-2
CP85-2
Reset

Results 9
Show
Model Number Imax (A) Vmax (V) Qmax (Th=27°C) (W) Qmax (Th=50°C) (W) ΔTmax (Th=27°C) ΔTmax (Th=50°C) Dimensions LxWxH (mm) Series
10 16.1 62 68 85 95 40 x 40 x 6.35 CP100
10 25.6 99 109 83 93 40.5 x 40 x 6.8 CP100
6.8 16 40 45 85 95 40 x 40 x 7.5 CP68H-2
6 14.2 32 35 82 92 41.25 x 45 x 6.7 CP60H-2
5 12.8 23 25 82 92 26.25 x 50 x 6.65 CP50-2
3.9 12.8 18 19.8 82 92 26.25 x 50 x 7.4 CP39H-2
3.6 16.7 21 23 82 92 31.25 x 30 x 6.7 CP39H-2
8.5 16.1 51.6 58 85 95 40 x 40 x 7.05 CP85-2
2.8 15.7 8.7 9.6 95 105 30 x 30 x 7.2 CP28-2
Results 9
Show
