SLW-883935-2A-D
8.8 x 3.9 x 3.5 mm, 2 mm Raised Slide Actuator, Right-Angle, Through Hole, Slide Switch
Specifications
| Type | Description | |
|---|---|---|
| Actuator Level | Raised |
|
| Actuator Type | Slide |
|
| Actuator Color | Black |
|
| Circuit | SPDT |
|
| Switch Function | On-On |
|
| Contact Timing | Non-shorting |
|
| Rated Voltage (Vdc) | 30 |
|
| Current Rating (mA) | 500 |
|
| Pitch (mm) | 2.5 |
|
| Mounting Style | Through Hole |
|
| Termination | PC Pin |
|
| Orientation | Horizontal |
|
| Dimensions LxWxH (mm) | 8.8 x 3.9 x 3.5 |
|
| Dimensions LxWxH (in) | 0.346 x 0.153 x 0.138 |
|
| Switch Type | Slide Switch |
|
