CP85204035

CP85204035

20 x 40 x 3.5 mm, 8.5 A Input with Leads, Peltier (TEC) Module

Datasheet

Specifications

Type Description
Select
Resistance (Ohms ± 10%) 0.75
Imax (A) 8.5
Vmax (V) 7.6
Qmax (Th=27°C) (W) 37.4
ΔTmax (Th=50°C) 75
Qmax (Th=50°C) (W) 41.8
ΔTmax (Th=27°C) 68
Dimensions LxWxH (mm) 20 x 40 x 3.5
Series CP85

Technical Docs

Datasheet 3D Model
