Specifications
| Type | Description | |
|---|---|---|
| S.P. Level (dB) | 78 (0.2 W / 0.5 m) |
|
| Max Input (W) | 0.3 |
|
| Nominal Input (W) | 0.2 |
|
| Impedance (Ohms) | 8 |
|
| Resonance Freq. (Hz) | 500 |
|
| Cone Type | PET |
|
| Magnet Type | Nd-Fe-B |
|
| Frame Shape | Round |
|
| Dimensions LxWxH (mm) | 30 x 30 x 3.9 |
|
| Dimensions LxWxH (in) | 1.18 x 1.18 x 0.15 |
|
| Mounting Style | Solder Pins/Posts |
|
