Specifications
| Type | Description | |
|---|---|---|
| S.P. Level (dB) | 93 (0.1 W / 0.05 m) |
|
| Max Input (W) | 0.4 |
|
| Nominal Input (W) | 0.25 |
|
| Impedance (Ohms) | 8 |
|
| Resonance Freq. (Hz) | 380 |
|
| Cone Type | PET |
|
| Magnet Type | Ferrite |
|
| Frame Shape | Round |
|
| Dimensions LxWxH (mm) | 38 x 38 x 9.4 |
|
| Dimensions LxWxH (in) | 1.5 x 1.5 x 0.37 |
|
| Mounting Style | Solder Pins/Posts |
|
