Specifications
| Type | Description | |
|---|---|---|
| Pitch (mm) | 2.54 |
|
| Actuator Type | Rotary |
|
| Number of Positions | 16 |
|
| Actuator Level | Flat |
|
| Actuator Style | Arrow |
|
| Bottom | Convex |
|
| Mounting Style | SMT |
|
| Pin | SMT |
|
| Switching Voltage Rating (Vdc) | 24 |
|
| Non-Switching Voltage Rating (Vdc) | 50 |
|
| Switching Current Rating (mA) | 25 |
|
| Non-Switching Current Rating (mA) | 100 |
|
| Termination | Gull Wing |
|
| Cap | No |
|
| Orientation | Horizontal |
|
| Dimensions LxWxH (mm) | 10 x 10 x 5.5 |
|
| Dimensions LxWxH (in) | 0.39 x 0.39 x 0.22 |
|
| Switch Type | DIP |
|
| Washable | No |
|
| Series | RDS-1055 |
|
