Specifications
| Type | Description | |
|---|---|---|
| S.P. Level (dB) | 98 (1 W / 0.5 m) |
|
| Max Input (W) | 20 |
|
| Nominal Input (W) | 10 |
|
| Impedance (Ohms) | 8 |
|
| Resonance Freq. (Hz) | 75 |
|
| Cone Type | Paper |
|
| Magnet Type | Ferrite |
|
| Frame Shape | Round |
|
| Dimensions LxWxH (mm) | 205 x 205 x 66 |
|
| Dimensions LxWxH (in) | 8.07 x 8.07 x 2.6 |
|
| Mounting Style | Solder Eyelet(s) |
|
