Specifications
| Type | Description | |
|---|---|---|
| S.P. Level (dB) | 91 (1 W / 0.5 m) |
|
| Max Input (W) | 2 |
|
| Nominal Input (W) | 1 |
|
| Impedance (Ohms) | 8 |
|
| Resonance Freq. (Hz) | 400 |
|
| Cone Type | Paper |
|
| Magnet Type | Ferrite |
|
| Frame Shape | Round |
|
| Dimensions LxWxH (mm) | 57 x 57 x 18.5 |
|
| Dimensions LxWxH (in) | 2.24 x 2.24 x 0.73 |
|
| Mounting Style | Solder Eyelet(s) |
|
