Specifications
| Type | Description | |
|---|---|---|
| S.P. Level (dB) | 100 (15 W / 0.5 m) |
|
| Nominal Input (W) | 15 |
|
| Max Input (W) | 20 |
|
| Impedance (Ohms) | 4 |
|
| Resonance Freq. (Hz) | 110 |
|
| Cone Type | SPCC |
|
| Magnet Type | Ferrite |
|
| Mounting Style | Solder Eyelet(s) |
|
| Frame Shape | Square |
|
| Dimensions LxWxH (in) | 4.02 x 4.02 x 2 |
|
| Dimensions LxWxH (mm) | 102 x 102 x 51 |
|
| Enclosed | No |
|
