Specifications
| Type | Description | |
|---|---|---|
| S.P. Level (dB) | 96 (1 W / 0.5 m) |
|
| Max Input (W) | 1 |
|
| Nominal Input (W) | 0.5 |
|
| Impedance (Ohms) | 8 |
|
| Resonance Freq. (Hz) | 580 |
|
| Cone Type | PET |
|
| Magnet Type | Nd-Fe-B |
|
| Frame Shape | Round |
|
| Dimensions LxWxH (mm) | 40 x 40 x 4.9 |
|
| Dimensions LxWxH (in) | 1.57 x 1.57 x 0.18 |
|
| Mounting Style | Solder Eyelet(s) |
|
