Specifications
| Type | Description | |
|---|---|---|
| S.P. Level (dB) | 81 (0.3 W / 0.5 m) |
|
| Nominal Input (W) | 0.3 |
|
| Max Input (W) | 0.5 |
|
| Impedance (Ohms) | 8 |
|
| Resonance Freq. (Hz) | 430 |
|
| Cone Type | PEI |
|
| Magnet Type | Nd-Fe-B |
|
| Mounting Style | Solder Pads |
|
| Frame Shape | Round |
|
| Enclosed | No |
|
| Dimensions LxWxH (in) | 1.4 x 1.4 x 0.19 |
|
| Dimensions LxWxH (mm) | 36 x 36 x 4.8 |
|
