Specifications
| Type | Description | |
|---|---|---|
| S.P. Level (dB) | 80 (1 W / 0.5 m) |
|
| Nominal Input (W) | 3 |
|
| Max Input (W) | 4 |
|
| Impedance (Ohms) | 8 |
|
| Resonance Freq. (Hz) | 380 |
|
| Cone Type | PU |
|
| Magnet Type | Nd-Fe-B |
|
| Dimensions LxWxH (mm) | 34 x 34 x 14.5 |
|
| Frame Shape | Square |
|
| Dimensions LxWxH (in) | 1.34 x 1.34 x 0.57 |
|
| Mounting Style | Solder Pads |
|
