Specifications
| Type | Description | |
|---|---|---|
| S.P. Level (dB) | 78 (0.5 W / 0.5 m) |
|
| Nominal Input (W) | 0.5 |
|
| Max Input (W) | 1 |
|
| Impedance (Ohms) | 8 |
|
| Resonance Freq. (Hz) | 570 |
|
| Cone Type | PET |
|
| Magnet Type | Nd-Fe-B |
|
| Mounting Style | Solder Pads |
|
| Frame Shape | Round |
|
| Enclosed | No |
|
| Dimensions LxWxH (in) | 0.74 x 0.74 x 0.12 |
|
| Dimensions LxWxH (mm) | 20 x 20 x 3 |
|
