Specifications
| Type | Description | |
|---|---|---|
| S.P. Level (dB) | 88 (0.5 W / 0.1 m) |
|
| Nominal Input (W) | 0.5 |
|
| Max Input (W) | 0.8 |
|
| Impedance (Ohms) | 8 |
|
| Resonance Freq. (Hz) | 850 |
|
| Cone Type | PI |
|
| Magnet Type | SmCo |
|
| Frame Shape | Square |
|
| Mounting Style | Surface Mount |
|
| Enclosed | No |
|
| Dimensions LxWxH (in) | 0.59 x 0.59 x 0.157 |
|
| Dimensions LxWxH (mm) | 15 x 15 x 4 |
|
