CDMG16008-03

CDMG16008-03

16 mm, Round Frame, 0.3 W, 8 Ohm, Neodymium Magnet, PET Cone, Speaker

Datasheet

Specifications

Type Description
Select
S.P. Level (dB) 82 (0.3 W / 0.1 m)
Max Input (W) 0.5
Nominal Input (W) 0.3
Impedance (Ohms) 8
Resonance Freq. (Hz) 600
Cone Type PET
Magnet Type Nd-Fe-B
Frame Shape Round
Dimensions LxWxH (mm) 16 x 16 x 2.55
Dimensions LxWxH (in) 0.63 x 0.63 x 0.1
Mounting Style Solder Pads

Technical Docs

Datasheet 3D Model
