Specifications
| Type | Description | |
|---|---|---|
| Driving Circuit | Yes |
|
| Rated Voltage | 5 |
|
| Input Type | Vdc |
|
| Sound Pressure (dB) | 90 |
|
| Mounting Style | Through Hole |
|
| Curr. Consumption (mA) | 15 |
|
| Rated Frequency (Hz) | 3500 |
|
| Shape | Round |
|
| Illumination | No |
|
| Dimensions LxWxH (in) | 0.93 x 0.93 x 0.63 |
|
| Dimensions LxWxH (mm) | 23.5 x 23.5 x 16 |
|
| Washable | No |
|
| IP Rating | No |
|
