HSS05-C20-SMT-TR

HSS05-C20-SMT-TR
HSS05-C20-SMT-TR Alternate View

HSS05-C20-SMT-TR

Stamped Heat Sink, TO-220, Copper, Surface Mount (SMT), No Pin

Datasheet

Specifications

Type Description
Select
Package Cooled TO-220
Mounting Style Surface Mount
Solder Pin Orientation No Pin
Thermal Resistance @ 75°C ΔT, nat conv (°C/W) 32.69
Thermal Resistance @ 1 W, nat conv (°C/W) 39.9
Thermal Resistance @ 1 W, 200 LFM (°C/W) 14
Thermal Resistance @ 1 W, 400 LFM (°C/W) 10.3
Power Dissipation @ 75°C ΔT, nat conv (W) 2.29
Material C1100
Material Finish Tin Plated
Dimensions LxWxH (mm) 12.7 x 26.2 x 9.91
Dimensions LxWxH (in) 0.5 x 1.03 x 0.39

Technical Docs

Datasheet 3D Model
