CBM-A232S-225-481-22
24 V, 360 mA, 120 x 120 x 32 mm, Dc Centrifugal Blower, Tachometer Signal, PWM Control Signal
Features
| Sleeve bearing construction |
| 120 x 120 mm frame |
| Multiple speed options for different cooling needs |
| Tachometer signal available |
| Auto restart protection standard on all models |
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Sleeve |
|
| Air Flow (CFM) | 23.07 |
|
| Rated Speed (RPM) | 2500 |
|
| Static Pressure (inH2O) | 0.94 |
|
| Noise (dBA) | 48.2 |
|
| Rated Voltage (Vdc) | 24 |
|
| Max Input Current (mA) | 360 |
|
| Tachometer Signal | Yes |
|
| Rotation Detector | No |
|
| PWM Control Signal | Yes |
|
| Dimensions LxWxH (mm) | 120 x 120 x 32 |
|
| Series | CBM-120S |
|
