CBM-7530CF-250-493-22
24 V, 0.45 A, 75.7 x 75.7 x 30 mm, Tachometer Signal, PWM Control Signal, omniCOOL™ Dc Centrifugal Blower
Thanks to the innovative omniCOOL™ system that provides improved performance and longer operational life, this centrifugal blower bridges the cost-performance gap between conventional sleeve and ball bearing fan designs.
Specifications
Type | Description | |
---|---|---|
Bearing Type | omniCOOL™ |
|
Air Flow (CFM) | 17.82 |
|
Rated Speed (RPM) | 5000 |
|
Static Pressure (inH2O) | 1.03 |
|
Noise (dBA) | 53.5 |
|
Rated Voltage (Vdc) | 24 |
|
Max Input Current (mA) | 450 |
|
Tachometer Signal | Yes |
|
Rotation Detector | No |
|
PWM Control Signal | Yes |
|
Dimensions LxWxH (mm) | 75.7 x 75.7 x 30 |
|
Operating Temp Range (°C) | -10 ~ 70 |
|
Series | CBM-75CF |
|
