CBM-7530CF-240-454
24 V, 0.23 A, 75.7 x 75.7 x 30 mm, omniCOOL™ Dc Centrifugal Blower
Thanks to the innovative omniCOOL™ system that provides improved performance and longer operational life, this centrifugal blower bridges the cost-performance gap between conventional sleeve and ball bearing fan designs.
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | omniCOOL™ |
|
| Air Flow (CFM) | 13.61 |
|
| Rated Speed (RPM) | 4000 |
|
| Static Pressure (inH2O) | 0.64 |
|
| Noise (dBA) | 48.1 |
|
| Rated Voltage (Vdc) | 24 |
|
| Max Input Current (mA) | 230 |
|
| Tachometer Signal | No |
|
| Rotation Detector | No |
|
| PWM Control Signal | No |
|
| Dimensions LxWxH (mm) | 75.7 x 75.7 x 30 |
|
| Series | CBM-75CF |
|
