CBM-7525C-245-494-22
24 V, 440 mA, 75 x 75 x 25 mm, Dc Centrifugal Blower, Tachometer Signal, PWM Control Signal
Thanks to the innovative omniCOOL™ system that provides improved performance and longer operational life, this centrifugal blower bridges the cost-performance gap between conventional sleeve and ball bearing fan designs.
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | omniCOOL™ |
|
| Air Flow (CFM) | 13.35 |
|
| Rated Speed (RPM) | 4500 |
|
| Static Pressure (inH2O) | 1.1 |
|
| Noise (dBA) | 49.4 |
|
| Rated Voltage (Vdc) | 24 |
|
| Max Input Current (mA) | 440 |
|
| Tachometer Signal | Yes |
|
| Rotation Detector | No |
|
| PWM Control Signal | Yes |
|
| Dimensions LxWxH (mm) | 75 x 75 x 25 |
|
| Series | CBM-75C |
|
