CBM-5020C-140-305
12 V, 0.09 A, 49.2 x 49.8 x 20 mm, omniCOOL™ Dc Centrifugal Blower
Thanks to the innovative omniCOOL™ system that provides improved performance and longer operational life, this centrifugal blower bridges the cost-performance gap between conventional sleeve and ball bearing fan designs.
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | omniCOOL™ |
|
| Air Flow (CFM) | 4.09 |
|
| Rated Speed (RPM) | 4000 |
|
| Static Pressure (inH2O) | 0.29 |
|
| Noise (dBA) | 30.5 |
|
| Rated Voltage (Vdc) | 12 |
|
| Max Input Current (mA) | 90 |
|
| Tachometer Signal | No |
|
| Rotation Detector | No |
|
| PWM Control Signal | No |
|
| Dimensions LxWxH (mm) | 49.2 x 49.8 x 20 |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
| Series | CBM-50C |
|
