CBM-4020B-160-367-22
12 V, 120 mA, 40 x 40 x 20 mm, Tachometer Signal, PWM Control Signal, Dc Centrifugal Blower
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Ball |
|
| Air Flow (CFM) | 2.66 |
|
| Rated Speed (RPM) | 6000 |
|
| Static Pressure (inH2O) | 0.19 |
|
| Noise (dBA) | 36.7 |
|
| Rated Voltage (Vdc) | 12 |
|
| Max Input Current (mA) | 120 |
|
| Tachometer Signal | Yes |
|
| Rotation Detector | No |
|
| PWM Control Signal | Yes |
|
| Dimensions LxWxH (mm) | 40 x 40 x 20 |
|
| Series | CBM-40B |
|
