CBM-4010C-140-178
12 V, 80 mA, 40 x 40 x 10 mm, Dc Centrifugal Blower
Thanks to the innovative omniCOOL™ system that provides improved performance and longer operational life, this centrifugal blower bridges the cost-performance gap between conventional sleeve and ball bearing fan designs.
Features
| omniCOOL™ bearing system |
| 40 x 40 mm frame |
| Multiple speed options for different cooling needs |
| Tachometer signal available |
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | omniCOOL™ |
|
| Air Flow (CFM) | 1.17 |
|
| Rated Speed (RPM) | 4000 |
|
| Static Pressure (inH2O) | 0.07 |
|
| Noise (dBA) | 17.8 |
|
| Rated Voltage (Vdc) | 12 |
|
| Max Input Current (mA) | 80 |
|
| Tachometer Signal | No |
|
| Rotation Detector | No |
|
| PWM Control Signal | No |
|
| Dimensions LxWxH (mm) | 40 x 40 x 10 |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
| Series | CBM-40C |
|
