CBM-A232B-220-457-22
24 V, 180 mA 120 x 120 x 32 mm, DC Centrifugal Blower, Tachometer Signal, PWM Control Signal
Features
| Dual ball bearing construction |
| 120 x 120 mm frame |
| Multiple speed options for different cooling needs |
| Tachometer signal available |
| Auto restart protection standard on all models |
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Ball |
|
| Air Flow (CFM) | 18.45 |
|
| Rated Speed (RPM) | 2000 |
|
| Static Pressure (inH2O) | 0.6 |
|
| Noise (dBA) | 45.8 |
|
| Rated Voltage (Vdc) | 24 |
|
| Max Input Current (mA) | 180 |
|
| Tachometer Signal | Yes |
|
| Rotation Detector | No |
|
| PWM Control Signal | Yes |
|
| Dimensions LxWxH (mm) | 120 x 120 x 32 |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
| Series | CBM-120B-2 |
|
