Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Ball |
|
| Air Flow (CFM) | 19.26 |
|
| Rated Speed (RPM) | 3000 |
|
| Static Pressure (inH2O) | 0.08 |
|
| Noise (dBA) | 29.5 |
|
| Rated Voltage (Vdc) | 24 |
|
| Max Input Current (mA) | 60 |
|
| Tachometer Signal | Yes |
|
| Rotation Detector | No |
|
| PWM Control Signal | No |
|
| Dimensions LxWxH (mm) | 70 x 70 x 15 |
|
| Series | CFM-70B |
|
