CPT-357-105T
CPT-357-105T
CPT-357-105T Alternate View

CPT-357-105T

35.6 mm, 14 Vdc, 105 dB, Wire Leads, Continuous Tone, Piezo Audio Transducer Buzzer

Datasheet

Specifications

Type Description
Select
Driving Circuit No
Rated Voltage 14
Input Type Vdc
Sound Pressure (dB) 105
Mounting Style Through Hole
Curr. Consumption (mA) 50
Shape Round
Washable No
Dimensions LxWxH (in) 1.4 x 1.4 x 0.28
IP Rating No
Dimensions LxWxH (mm) 35.6 x 35.6 x 7.15
