Specifications
| Type | Description | |
|---|---|---|
| Driving Circuit | No |
|
| Input Type | Vp-p |
|
| Rated Voltage | 25 |
|
| Sound Pressure (dB) | 73 |
|
| Mounting Style | Surface Mount |
|
| Curr. Consumption (mA) | 4.5 |
|
| Operating Temp Range (°C) | -40 ~ 80 |
|
| Shape | Rectangular |
|
| Dimensions LxWxH (mm) | 11 x 9 x 1.7 |
|
| Dimensions LxWxH (in) | 0.43 x 0.35 x 0.07 |
|
| Washable | No |
|
