CFM-5020C-260-367
24 V, 70 mA, 50 x 50 x 20 mm, omniCOOL™ Dc Fan
Thanks to the innovative omniCOOL™ system that provides improved performance and longer operational life, this axial fan bridges the cost-performance gap between conventional sleeve and ball bearing fan designs.
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | omniCOOL™ |
|
| Air Flow (CFM) | 18.23 |
|
| Rated Speed (RPM) | 6000 |
|
| Static Pressure (inH2O) | 0.26 |
|
| Noise (dBA) | 36.7 |
|
| Rated Voltage (Vdc) | 24 |
|
| Max Input Current (mA) | 110 |
|
| Tachometer Signal | No |
|
| Rotation Detector | No |
|
| PWM Control Signal | No |
|
| Dimensions LxWxH (mm) | 50 x 50 x 20 |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
| Series | CFM-50C |
|
