Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Ball |
|
| Air Flow (CFM) | 147.86 |
|
| Rated Speed (RPM) | 3200 |
|
| Static Pressure (inH2O) | 0.39 |
|
| Noise (dBA) | 51.9 |
|
| Rated Voltage (Vdc) | 24 |
|
| Max Input Current (mA) | 520 |
|
| Tachometer Signal | Yes |
|
| Rotation Detector | No |
|
| PWM Control Signal | No |
|
| Dimensions LxWxH (mm) | 120 x 120 x 38 |
|
| Series | CFM-A2BJ |
|
