CFM-A225B-125-398-22

CFM-A225B-125-398-22

12 V, 410 mA, 120 x 120 x 25 mm, Dc Fan, Tachometer Signal, PWM Control Signal

Datasheet

Features

Dual ball bearing construction
120 x 120 mm frame
Multiple speed options for different cooling needs
Tachometer signal available
Auto restart protection standard on all models

Specifications

Type Description
Select
Bearing Type Ball
Max Input Current (mA) 410
Dimensions LxWxH (mm) 120 x 120 x 25
Operating Temp Range (°C) -10 ~ 70
Series CFM-120B
Air Flow (CFM) 87.18
Noise (dBA) 42.7
PWM Control Signal Yes
Rated Speed (RPM) 2500
Rated Voltage (Vdc) 12
Rotation Detector No
Static Pressure (inH2O) 0.13
Tachometer Signal Yes

Technical Docs

Datasheet 3D Model
