CFM-120 Series

CFM-A225-43-10

48 V, 0.17 A, 120 x 120 x 25.4 mm, Dc Fan

Datasheet

Features

High fan speed for greater air flow
Dual ball bearing construction
Auto restart protection standard on all models
120 x 120 mm frame

Specifications

Type Description
Select
Bearing Type Ball
Air Flow (CFM) 126.89
Rated Speed (RPM) 4100
Static Pressure (inH2O) 0.493
Noise (dBA) 53.5
Rated Voltage (Vdc) 48
Max Input Current (mA) 230
Tachometer Signal No
Rotation Detector No
PWM Control Signal No
Dimensions LxWxH (mm) 120 x 120 x 25.4
Operating Temp Range (°C) -10 ~ 70
Series CFM-120
