Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Ball |
|
| Air Flow (CFM) | 151.06 |
|
| Rated Speed (RPM) | 11000 |
|
| Static Pressure (inH2O) | 2.9 |
|
| Noise (dBA) | 66.3 |
|
| Rated Voltage (Vdc) | 24 |
|
| Max Input Current (mA) | 1670 |
|
| Tachometer Signal | Yes |
|
| Rotation Detector | No |
|
| PWM Control Signal | No |
|
| Dimensions LxWxH (mm) | 92 x 92 x 38 |
|
| Series | CFM-92BF |
|
