Features
| 92 x 92 mm frame |
| Multiple speed options for different cooling needs |
| Auto restart protection standard on all models |
| Dual ball bearing construction |
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Ball |
|
| Air Flow (CFM) | 92.24 |
|
| Rated Speed (RPM) | 4800 |
|
| Static Pressure (inH2O) | 0.63 |
|
| Noise (dBA) | 52.3 |
|
| Rated Voltage (Vdc) | 12 |
|
| Max Input Current (mA) | 950 |
|
| Tachometer Signal | Yes |
|
| Rotation Detector | No |
|
| PWM Control Signal | No |
|
| Dimensions LxWxH (mm) | 92 x 92 x 38 |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
| Series | CFM-92B |
|
