Features
| 92 x 92 mm frame |
| Multiple speed options for different cooling needs |
| Auto restart protection standard on all models |
| Sleeve bearing construction |
Specifications
| Type | Description | |
|---|---|---|
| Air Flow (CFM) | 102.79 |
|
| Bearing Type | Sleeve |
|
| Rated Speed (RPM) | 5000 |
|
| Static Pressure (inH2O) | 0.62 |
|
| Noise (dBA) | 51 |
|
| Rated Voltage (Vdc) | 12 |
|
| Max Input Current (mA) | 910 |
|
| Tachometer Signal | No |
|
| Rotation Detector | No |
|
| PWM Control Signal | No |
|
| Dimensions LxWxH (mm) | 92 x 92 x 32 |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
| Series | CFM-92S |
|
