Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Ball |
|
| Air Flow (CFM) | 70.17 |
|
| Rated Speed (RPM) | 4000 |
|
| Static Pressure (inH2O) | 0.37 |
|
| Noise (dBA) | 43.8 |
|
| Rated Voltage (Vdc) | 24 |
|
| Max Input Current (mA) | 300 |
|
| Tachometer Signal | No |
|
| Rotation Detector | No |
|
| PWM Control Signal | No |
|
| Dimensions LxWxH (mm) | 92 x 92 x 25 |
|
| Series | CFM-92BG |
|
