CFM-9225BG-160-545

CFM-9225BG-160-545

12 V, 820 mA, 92 x 92 x 25 mm, Dc Fan

Datasheet

Specifications

Type Description
Select
Bearing Type Ball
Air Flow (CFM) 106.54
Rated Speed (RPM) 6000
Static Pressure (inH2O) 0.8
Noise (dBA) 54.5
Rated Voltage (Vdc) 12
Max Input Current (mA) 980
Tachometer Signal No
Rotation Detector No
PWM Control Signal No
Dimensions LxWxH (mm) 92 x 92 x 25
Series CFM-92BG

Technical Docs

Datasheet 3D Model
