CFM-9225BG-140-438-22
12 V, 360 mA, 92 x 92 x 25 mm, Dc Fan, Tachometer Signal, PWM Control Signal
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Ball |
|
| Air Flow (CFM) | 70.17 |
|
| Rated Speed (RPM) | 4000 |
|
| Static Pressure (inH2O) | 0.37 |
|
| Noise (dBA) | 43.8 |
|
| Rated Voltage (Vdc) | 12 |
|
| Max Input Current (mA) | 540 |
|
| Tachometer Signal | Yes |
|
| Rotation Detector | No |
|
| PWM Control Signal | Yes |
|
| Dimensions LxWxH (mm) | 92 x 92 x 25 |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
| Series | CFM-92BG |
|
