CFM-7015C-250-406-22
24 V, 0.17 A, 70 x 70 x 15 mm, Tachometer Signal, PWM Control Signal, omniCOOL™ Dc Axial Fan
Thanks to the innovative omniCOOL™ system that provides improved performance and longer operational life, this axial fan bridges the cost-performance gap between conventional sleeve and ball bearing fan designs.
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | omniCOOL™ |
|
| Air Flow (CFM) | 32.1 |
|
| Rated Speed (RPM) | 5000 |
|
| Static Pressure (inH2O) | 0.22 |
|
| Noise (dBA) | 40.6 |
|
| Rated Voltage (Vdc) | 24 |
|
| Max Input Current (mA) | 170 |
|
| Tachometer Signal | Yes |
|
| Rotation Detector | No |
|
| PWM Control Signal | Yes |
|
| Dimensions LxWxH (mm) | 70 x 70 x 15 |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
| Series | CFM-70C |
|
