CFM-6025CF-235-274-22
24 V, 0.08 A, 60 x 60 x 25 mm, Dc Fan, Tachometer Signal, PWM Control Signal
The CFM-60CF series is a family of 60 x 60 mm dc axial fans featuring airflows up to 31.13 CFM and rated speeds from 2500 to 6500 RPM. Thanks to the innovative omniCOOL™ system that provides improved performance and longer operational life, these axial fans bridge the cost-performance gap between conventional sleeve and ball bearing fan designs.
Features
| omniCOOL™ bearing system |
| 60 x 60 mm frame |
| Multiple speed options for different cooling needs |
| Tachometer signal available |
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | omniCOOL™ |
|
| Max Input Current (mA) | 80 |
|
| Dimensions LxWxH (mm) | 60 x 60 x 25 |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
| Series | CFM-60CF |
|
| Air Flow (CFM) | 16.76 |
|
| Noise (dBA) | 27.5 |
|
| PWM Control Signal | Yes |
|
| Rated Speed (RPM) | 3500 |
|
| Rated Voltage (Vdc) | 24 |
|
| Rotation Detector | No |
|
| Static Pressure (inH2O) | 0.11 |
|
| Tachometer Signal | Yes |
|
