CFM-3510BF-170-222-22

CFM-3510BF-170-222-22

12 V, 0.09 A, 35 x 35 x 10 mm, Dc Fan, Tachometer Signal, PWM Control Signal

Datasheet

Features

35 x 35 mm frame
Dual ball bearing construction
Multiple speed options for different cooling needs
Tachometer signal available

Specifications

Type Description
Select
Bearing Type Ball
Max Input Current (mA) 90
Dimensions LxWxH (mm) 35 x 35 x 10
Operating Temp Range (°C) -10 ~ 70
Series CFM-35CF
Air Flow (CFM) 4.59
Noise (dBA) 22.3
PWM Control Signal Yes
Rated Speed (RPM) 7000
Rated Voltage (Vdc) 12
Rotation Detector No
Static Pressure (inH2O) 0.1
Tachometer Signal Yes

Technical Docs

Datasheet 3D Model
