CFM-2507CF-050-089-20
5 V, 0.08 A, 25 x 25 x 7 mm, Tachometer Signal, omniCOOL™ Dc Axial Fan
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | omniCOOL™ |
|
| Air Flow (CFM) | 1.1 |
|
| Rated Speed (RPM) | 5000 |
|
| Static Pressure (inH2O) | 0.03 |
|
| Noise (dBA) | 9 |
|
| Rated Voltage (Vdc) | 5 |
|
| Max Input Current (mA) | 80 |
|
| Tachometer Signal | Yes |
|
| Rotation Detector | No |
|
| PWM Control Signal | No |
|
| Dimensions LxWxH (mm) | 25 x 25 x 7 |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
| Series | CFM-25CF |
|
