CFM-A751BF-135-533-22
12 V, 0.84 A, 172 x 151.5 x 51.5 mm, Dc Fan, Tachometer Signal, PWM Control Signal
Features
| 172 x 151.5 mm frame |
| Multiple speed options for different cooling needs |
| Dual ball bearing construction |
| Auto restart protection standard on all models |
| Tachometer signal available |
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Ball |
|
| Max Input Current (mA) | 2070 |
|
| Dimensions LxWxH (mm) | 172 x 151.5 x 51.5 |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
| Series | CFM-A7BF |
|
| Air Flow (CFM) | 252.7 |
|
| Noise (dBA) | 53.3 |
|
| PWM Control Signal | Yes |
|
| Rated Speed (RPM) | 3500 |
|
| Rated Voltage (Vdc) | 12 |
|
| Rotation Detector | No |
|
| Static Pressure (inH2O) | 0.65 |
|
| Tachometer Signal | Yes |
|
