CFM-A238B-226-435-22
24 V, 270 mA, 120 x 120 x 38 mm, Dc Fan, Tachometer Signal, PWM Control Signal
Features
Dual ball bearing construction |
120 x 120 mm frame |
Multiple speed options for different cooling needs |
Tachometer signal available |
Auto restart protection standard on all models |
Specifications
Type | Description | |
---|---|---|
Bearing Type | Ball |
|
Max Input Current (mA) | 270 |
|
Dimensions LxWxH (mm) | 120 x 120 x 38 |
|
Series | CFM-120B |
|
Air Flow (CFM) | 100.71 |
|
Noise (dBA) | 43.5 |
|
PWM Control Signal | Yes |
|
Rated Speed (RPM) | 2600 |
|
Rated Voltage (Vdc) | 24 |
|
Rotation Detector | No |
|
Static Pressure (inH2O) | 0.24 |
|
Tachometer Signal | Yes |
|
