CFM-A225BF-163-615-22
12 V, 3.16 A, 120 x 120 x 25 mm, Dc Fan, Tachometer Signal, PWM Control Signal
Features
| 120 x 120 mm frame |
| Multiple speed options for different cooling needs |
| Dual ball bearing construction |
| Auto restart protection standard on all models |
| Tachometer signal available |
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Ball |
|
| Max Input Current (mA) | 3160 |
|
| Dimensions LxWxH (mm) | 120 x 120 x 25 |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
| Series | CFM-120BF |
|
| Air Flow (CFM) | 201.4 |
|
| Noise (dBA) | 61.5 |
|
| PWM Control Signal | Yes |
|
| Rated Speed (RPM) | 6300 |
|
| Rated Voltage (Vdc) | 12 |
|
| Rotation Detector | No |
|
| Static Pressure (inH2O) | 1.16 |
|
| Tachometer Signal | Yes |
|
