CFM-A225BF-158-597

CFM-A225BF-158-597

12 V, 2.40 A, 120 x 120 x 25 mm, Dc Fan

Datasheet

Features

120 x 120 mm frame
Multiple speed options for different cooling needs
Dual ball bearing construction
Auto restart protection standard on all models
Tachometer signal available

Specifications

Type Description
Select
Bearing Type Ball
Max Input Current (mA) 2400
Dimensions LxWxH (mm) 120 x 120 x 25
Operating Temp Range (°C) -10 ~ 70
Series CFM-120BF
Air Flow (CFM) 185.5
Noise (dBA) 59.7
PWM Control Signal No
Rated Speed (RPM) 5800
Rated Voltage (Vdc) 12
Rotation Detector No
Static Pressure (inH2O) 0.98
Tachometer Signal No

Technical Docs

Datasheet 3D Model
